New Old Stock ZF 220A 2.040:1 Ratio Marine Gearbox. Ready to Install !!
ZF 220A 2.040:1 Ratio Marine Transmission / Gearbox
$1,889.00
New Old Stock ZF 220A 2.040:1 Ratio Marine Gearbox. Ready to Install !!
New ZF 220A 2.040:1 Ratio Gearbox Marine. Old Stock, Never Installed!
The ZF Marine 220A (also known as the ZF-Hurth 220A or IRM220A-1) with a 2.040:1 gear ratio is a reverse-reduction marine transmission featuring hydraulically actuated multi-disc clutches designed for high-performance pleasure craft and light commercial duties.
SPECIFICATION
Gear Ratio: 2.040:1 (Forward), 2.040:1 (Reverse)
Down Angle: 10 degrees
Weight (Dry): Approx. 110 lbs / 50 kg
Oil Capacity: Approx. 4 liters (approx. 4.2 qts)
Shift: Mechanical (standard)
Input Rotation: Standard rotation (clockwise)
Power Ratings:
- Pleasure Duty (3200 RPM): 400 HP / 298 kW
- Light Duty (2800 RPM): 329 HP / 246 kW
- Medium Duty (2800 RPM): 262 HP / 195 kW
Max Input Speed: 4500 RPM (Pleasure/Light), 3200 RPM (Medium/Continuous)
FEATURES
- Lightweight and robust aluminum alloy casing (sea water resistant)
- Case hardened and precisely ground gear teeth for long life and smooth running
- Output shaft thrust bearing designed to take maximum propeller thrust astern and ahead
- Smooth and reliable hydraulic shifting with control lever for attachment of push-pull cable
- Suitable for twin engine installations (same ratio and torque capacity in ahead or astern mode)
- Replaceable oil filter cartridge
- Compact, space saving design; 10° down-angle and "Lambda" beveloid gear principle
