Used ZF Marine IRM 310 AL Marine Transmission With 2.558:1 Ratio. Very Good Condition and Ready to Install !!
ZF Marine IRM 310 AL Marine Gearbox 2.558:1 Ratio
$2,788.00
Used ZF Marine IRM 310 AL Marine Transmission With 2.558:1 Ratio. Very Good Condition and Ready to Install !!
ZF Marine IRM 310 AL 2.558:1 Ratio Marine Gearbox / Transmission
The ZF Marine IRM 310 AL with a 2.558:1 reduction ratio is a heavy-duty marine reverse and reduction gearbox engineered for commercial and pleasure craft propulsion systems. Provides smooth and efficient power transmission from the engine to the propeller, allowing for better maneuverability and control.
SPECIFICATION
Configuration: 310 A (Down-angle, usually 7° or 10°) or 310 PL (Coaxial)
Maximum Power: 600 HP (at 2300 RPM)
Gear Ratios: 2.558:1
Shifting: Mechanical
Weight (Dry): Approximately 182 kg
Oil Capacity: 2.38 US Gal (approx. 9 liters)
Oil Pressure: Nominal pressure approx. 22 bar
Bell Housing: SAE 1 or similar
KEY FEATURES
Robust Aluminum Alloy Housing (AL): Provides a lightweight yet highly durable structural framework resistant to marine environments.
Reverse-Reduction Capability: Efficiently reverses propeller rotation while stepping down shaft speed for optimized thrust and propeller efficiency.
Precision Helical Gearing: Designed for smooth, quiet operation and high load-carrying capacity under continuous operational stress.
Modular Options: Accommodates auxiliary equipment setups depending on specific vessel engineering layout.
