Brand New Yanmar 3YM30AE 29.1-HP Inboard Diesel Engine. Open Box, Ready to Install !!
Yanmar 3YM30AE Inboard Diesel Engine 29.1-HP
$5,020.00
Brand New Yanmar 3YM30AE 29.1-HP Inboard Diesel Engine. Open Box, Ready to Install !!
Yanmar 3YM30AE 1.266L 3-Cylinder 29.1 HP Inboard Diesel Engine
The Yanmar 3YM30AE is a 29.1 mhp (21.3 kW) at 3200 rpm, 3-cylinder, 4-stroke vertical water-cooled marine diesel engine. It features natural aspiration, indirect injection, a 1.266 L displacement, and weighs 127 kg. Designed for sailboats and small craft.
SPECIFICATION
Model: Yanmar 3YM30AE
Maximum Output: 21.3 kW / 29.1 mhp (HP)
Rated Speed: 3200 rpm
Displacement: 1.266 litres (77 cu in)
Bore x Stroke: 80 mm x 84 mm (3.15 in x 3.31 in)
Cylinders: 3 cylinders (in-line)
Combustion System: Indirect Injection (In-line pump)
Aspiration: Natural
Starting System: Electric starting 12V - 1.4 kW
Alternator: 12V - 125A
Cooling System: Fresh water cooling with heat exchanger
Lubrication System: Enclosed, forced lubricating system
Rotation: Counterclockwise viewed from flywheel side (Propeller clockwise)
Dry Weight: 127 kg (280 lbs)
Dimensions : 715 mm x 462 mm x 545 mm
Engine Oil: API Class CD or higher, SAE 10W30 or 15W40
Emissions: RCD 2, EPA Tier 3, EPA Tier 3C, BSO II, EMC
FEATURES
Emissions & Fuel: Complies with major US and EU standards and is HVO-approved.
Drives: Compatible with the KM2P-1 mechanical cone clutch marine gear or SD25 saildrive.
