Used Tohatsu M9.8B Outboard Motor. Excellent Condition and Ready to Go !!
Tohatsu 9.8 HP 2-Stroke Outboard Motor M9.8B
$720.00
Used Tohatsu M9.8B Outboard Motor. Excellent Condition and Ready to Go !!
Tohatsu M9.8B 2-Stroke 2-Cylinder 9.8 HP Outboard Motor
The Tohatsu M9.8B is a portable 9.8 hp, two-stroke outboard motor known for its high power-to-weight ratio and lightweight design.
SPECIFICATION
Engine Type: 2-stroke, 2-cylinder
Max Output: 7.2 kW (9.8 PS / 9.8 hp)
Displacement: 169 cc (10.3 cu. in.)
Bore & Stroke: 50 x 43 mm (1.97 x 1.69 in.)
Maximum RPM Range: 5,000 – 6,000 RPM
Fuel Ratio (Pre-Mix): 25:1 during break-in, then 50:1 (Unleaded 87 octane gasoline + TCW-3 2-stroke oil)
Fuel Tank: 12-liter (3.17 US Gal.) separate external fuel tank
Gear Shift: Forward – Neutral – Reverse (F-N-R)
Gear Ratio: 2.08:1 (27:13)
Gear Oil: API GL-5, SAE 80-90 (approx. 320 mL)
Spark Plug: NGK BP7HS-10 or BPR7HS-10 (gap: 0.9–1.0 mm)
Propeller Range: 5" to 9.5" pitch (3-blade aluminum)
Dry / Minimum Weight: 26 kg (57 lbs)
KEY FEATURES
Engine Design: 2-cylinder, loop-charged induction for smooth operation and fuel economy.
Ignition System: CD (Capacitor Discharge) ignition for quick, reliable starts and crisp throttle response.
Cooling System: Thermostatically controlled water cooling system to maintain a consistent engine temperature.
Exhaust: Through-the-propeller exhaust for a quieter ride.
Corrosion Protection: Marine aluminum alloy exterior with an internal zinc coating for salt-water durability.
Safety & Control: Start-in-gear protection, safety lanyard/emergency stop switch, shallow-water drive, and an automatic reverse lock.
Starting & Steering Options: Available in manual (recoil) or electric start, with tiller handle or remote control configurations.
